The full-automatic acid value tester is developed according to GB/T264 and is mainly used to measure the acid value of transformer oil, turbine oil and other petroleum products. It can be widely used in power, petroleum, chemical, commodity inspection and scientific research departments.
Technical features:
Double CPU microcomputer control
The detection system adopts imported laser devices, with low power and long service life
Automatic titration to judge the end point
Automatic extraction, neutralization, cup rotation, detection, printing, etc
LCD display, no identification button
Technical parameters:
|
Measurement range |
0.0001 ～ 0.9999mgKOH/g |
|
Accuracy Acid value |
0.001 ～ 0.1mgKOH/g ± 0.01mgKOH/g |
|
Acid value |
between 0.1~0.4mgKOH/g, 5% of the indicated value |
|
Repeatability |
0.02mgKOH/g |
|
Resolution |
0.0001mgKOH/g |
|
Measurement method |
Neutralization method |
|
Display mode |
LCD (240 × 128) |
|
Power supply voltage AC |
220V ± 10% 50Hz ± 10% |
|
Ambient temperature |
5 ℃～ 40 ℃ |
|
Relative humidity |
≤ 85% |
|
Overall dimension |
480mm × 340mm × 200mm |
|
|
Thermal Print |
|
Power |
60W |
|
Weight |
12.5kg |
